产品编号 | 349006119 | 349006121 | 349006128 | 349006130 | 349006140 | 349006141 | 349006142 | 349006143 |
---|
描述 | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Medium Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key A, Black Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Medium Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key C, Dark Gray Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Medium Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key B, Light Gray Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Medium Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key D, Stone Gray Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Long Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key A, Black Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Long Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key B, Light Gray Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Long Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key C, Dark Gray Insert | MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Long Shroud (T3-V2-S3 with Backshell, T3-V2-S2 without Backshell), Key D, Stone Gray Insert |
---|
常规 |
状态 | Active | Active | Active | Active | Active | Active | Active | Active |
---|
类别 | Connector Housings | Connector Housings | Connector Housings | Connector Housings | Connector Housings | Connector Housings | Connector Housings | Connector Housings |
---|
Series | 34900 | 34900 | 34900 | 34900 | 34900 | 34900 | 34900 | 34900 |
---|
应用 | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire | Automotive,Body Electronics,Sealed,Wire-to-Wire |
---|
个评论 | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. | See sales drawing for terminal information. |
---|
产品名称 | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed | MXP120 Sealed |
---|
UPC | 889056198073 | 889056198097 | 889056198080 | 889056198103 | 889056198035 | 889056198042 | 889056198059 | 889056198066 |
---|
物理 |
电路数(最多) | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
---|
颜色-树脂 | Black | Black | Black | Black | Black | Black | Black | Black |
---|
性别 | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle |
---|
符合灼热丝规范 | No | No | No | No | No | No | No | No |
---|
插接极性 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
---|
锁定插接部位 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
---|
材料 - 树脂 | SPS/Nylon | SPS/Nylon | SPS/Nylon | SPS/Nylon | SPS/Nylon | SPS/Nylon | SPS/Nylon | SPS/Nylon |
---|
净重 | 6.010/g | 6.140/g | 6.090/g | 6.130/g | 6.500/g | 6.500/g | 6.500/g | 6.500/g |
---|
行数 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
---|
包装形式 | Bag | Bag | Bag | Bag | Bag | Bag | Bag | Bag |
---|
面板安装式 | No | No | No | No | No | No | No | No |
---|
间距 - 插配接口 | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm |
---|
间距 - 终端界面 | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm | 4.00mm |
---|
极化 | A | C | B | D | A | B | C | D |
---|
有极性的插配件 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
---|
运行温度范围 | -40° to +125°C | -40° to +125°C | -40° to +125°C | -40° to +125°C | -40° to +125°C | -40° to +125°C | -40° to +125°C | -40° to +125°C |
---|
Solder Process Data |
无铅 | - | N/A | N/A | - | - | - | - | - |
---|
产品环境合规 |
China RoHS | per SJ/T 11365-2006 | per SJ/T 11365-2006 | per SJ/T 11365-2006 | per SJ/T 11365-2006 | per SJ/T 11365-2006 | Not Relevant | per SJ/T 11365-2006 | per SJ/T 11365-2006 |
---|
EU ELV | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC | Compliant per 2000/53/EC |
---|
EU RoHS | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 | Compliant per EU 2015/863 |
---|
GADSL/IMDS | Compliant | Duty-To-Declare | Compliant | Compliant | Duty-To-Declare | Compliant | Duty-To-Declare | Compliant |
---|
Low-Halogen Status | Low-Halogen per IEC 61249-2-21 | Low-Halogen per IEC 61249-2-21 | Low-Halogen per IEC 61249-2-21 | Low-Halogen per IEC 61249-2-21 | Low-Halogen per IEC 61249-2-21 | Not Relevant | Low-Halogen per IEC 61249-2-21 | Not Relevant |
---|
Prop65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 | Compliant per California Proposition 65 |
---|
REACH SVHC | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) | Not Contained per D(2023)8585-DC (23 Jan 2024) |
---|
配插使用 |
产品编号 | 34899 | 34899 | 34899 | 34899 | 34899 | 34899 | 34899 | 34899 |
---|
可装的端子等部件 |
产品编号 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 | 1600916020, 1600916120, 1600916220, 0349961501, 0349961902 |
---|
施工工具 |
产品编号 | 0638246300 | 0638246300 | 0638246300 | 0638246300 | 0638246300 | 0638246300 | 0638246300 | 0638246300 |
---|
